Using the linear principle of the stapler, when pulling the handle, the lever increases the grip force to more than 5 times, which is transmitted to the slide block. The slide block is pushed forward together with the push-pin rod to push the pinout of the bin, the nail penetrates the tissue to be sutured, but because of the resistance of the guide groove on the board, the nail foot bends inwards to form a B shape, firmly sealing the two layers of tissue. The procedure for using the endoscopic linear stapler is as follows:

1. Remove the endoscopic linear stapler cover (needle plate);

2. The two sides of the tissue incision are respectively clamped with tissue clamps and the site to be anastomoses is lifted, and the tissue is placed on the head of the stapler;

3. The positioning pin rod in the assembly is automatically entered into the set of nails when the firing is started by holding the firing handle, and the matched tissue is confined in the matched area;

4. When the firing handle is pushed halfway, the firing handle can be saved automatically by itself. At this time, there will be a sound to prompt the doctor to adjust the anastomotic site of the tissue accurately according to the situation;

5. After adjusting the fitting part, continue to hit the firing handle until the tissue is completely locked, there will be a sound prompt, the firing handle will automatically spring open at this time, if not, open it manually to ensure that the firing, the handle is fully open;

6. When the firing handle is pressed again to match the tissue, there will be a sound prompt when the firing is in place, and the staple penetrates both sides of the tissue to complete the b-shaped suture. At this point, the firing handle is in a fully locked state, two strikes are not allowed to protect the anastomotic site and tissues from injury;

7. Remove excess tissue;

8. Press the reset button, all parts automatically back, check the tissue anastomosis site, whether there is leakage needle phenomenon (bleeding, leakage) if there should be timely hand suture;

9. After the completion of the exit product should be careful, do not use violence or force pull out of the product.

Jiangsu Qianjing Medical Equipment Co., Ltd.’s existing products have covered all kinds of stapler such as endoscopic linear stapler, tubular stapler, linear cutting stapler, linear stapler, arc cutting stapler, Skin Stapler, piercer, incision retractor, purse stapler, etc, meet the needs of various surgical operations. A mask production line has been added this year. If you want more information, you can send an e-mail to sales@qjmed.com.
